TG-PowerStone-33k64E
PowerStone Series Small C&l ESS
Contact
Products C&I Energy Storage Series
Product advantages
All-In-One Plug-and-Play Integration
PV-storage-diesel (built-in ATS) architecture integrates all core functions. No extra components needed, ready to use, reducing deployment and procurement costs.
100% Unbalanced Three-Phase Load Support
Self-developed inverter topology enables full unbalanced load operation without derating. Single-phase full power output, perfect for mixed single/three-phase loads.
Multi-Energy Microgrid Capability
Supports PV, diesel, DC fan integration with optimized diesel efficiency (60-80% load). Four core operation modes, perfect for no-grid/frequent outage scenarios.
Modular Easy-Maintenance Design
Drawer-type power modules replaceable in 10 mins by one person. Multi-mode firmware upgrade, 80% faults resolved remotely, ideal for emerging markets.
Technical specifications
ModelTG-PowerStone-33k64E
Battery Parameters
Battery TypeLFP
Rated Energy64.3kWh
Rated Voltage51.2V
Voltage Range44.8～57.6V
PV Parameters
Max.PV Array power39kW
MPPT Voltage Range60Vdc～450Vdc
Max.Charging Current480A(PV+Battery)
AC Side Parameters
Rated Power33kW
Rated Grid Voltage &FrequencyAC400V/230V&50/60Hz
Input Voltage Range295-485VAC(UPS)
156-485VAC(Load Side)
Peak Efficiency96%
Overload Capacity60s@105%~110% Load
10s@110%~140% Load
5s@≥140% Load
Other Parameters
Weight≤650kg
Dimensions (W*D*H)750*850*2000mm
Cooling MethodAir  cooling
Operating Temperature-20～+55℃
Enclosure Protection RatingIP54
Fire Protection ConfigurationPACK Class+Aerosol
To learn more about energy storage solutions, please contact us!
